S5265 51.2V 65AH Solar Energy Low Voltage Battery Ampleness

    • LiFePO4 Prismatic Cells:Available for 48v system

    • Cycle life:>6,000 Cycles at 90% DOD
    • Customizable:Indoor or outdoor cabinets as request
    • Intelligent BMS:Wider compatibility
    • Scalable: paralleled 16 sets:Battery:3.3kWh – 53.2kWh
    • Compact Design and Safety Protection
MODEL:
Place of Origin  China, Jiangsu
Brand Name  Ampleness
Model Number  S5265
Certification  UN38.3, MSDS,CB(IEC62133) CE-MEC(61000)

65AH

  • Product Description
  • Product Details
  • Product Description

    S5265 offers reliable and long-lasting performance, ensuring a consistent power supply for your solar system.

    description-img
    Leading Features
    • 01

      long service life

    • 02

      LFP Prismatic Cell

    • 03

      51.2V low-voltage

    • 04

      BMS

    Certificates

    CUL
    CUL
    MH66503
    TUV

    Package

    s5265
    packing-1
    packing
    packing-3
    Careful packaging:

    We focus on packaging quality, using tough cartons and foam to protect products in transit, with clear usage instructions.

    Secure shipping:

    We partner with trusted logistics providers, ensuring products are well-protected.

    Related Products

    A5120 51.2V 100AH 5.12KWH Lithium Ion Battery Ultra-thin for House

    A5120 51.2V 100A

    AW5120 51.2V 100AH 5.12KWH Wall Mounted LiFePO4 Solar Battery Ultra-thin for House Amensolar

    AW5120 100AH

    POWER BOX 51.2V 200AH 10.24KWH Wall Mount Solar Battery Amensolar

    POWER BOX 51.2V 200AH

    POWER WALL 51.2V 200AH 10.24KWH Wall Mount Solar Battery Amensolar

    POWER WALL 200A

    AS5120 51.2V 100AH 5.12KWH Stack Mounted LifePo4 Solar Battery Amensolar

    AS5120

    AM5120S 51.2V 100AH 5.12KWH  Rack-Mounted LiFePO4 Solar Battery

    AM5120S 51.2V 100AH

    Battery Type LifePo4
    Mount Type Rack Mounted
    Nominal Voltage (V) 51.2
    Capacity(Ah) 65
    Nominal Energy (KWh) 3.33
    Operating Voltage(V) 43.2~57.6
    Max Charge Current(A) 70
    charging Current(A) 60
    Max Discharge Current(A) 70
    discharging current(A) 60
    charging Temperature 0℃~+55℃
    Discharging Temperature ﹣ 10℃-55℃
    Relative Humidity 0-95%
    Dimension(L*W*H mm) 502*461.5* 176
    Weight(KG) 46.5±1
    Communication CAN, RS485
    Enclosure Protection Rating IP53
    Cooling Type Natural Cooling
    Cycles Life >3000
    Recommend  DOD 90%
    Design Life 10+ Years (25℃@77F)
    Safety Standard CE/UN38.3
    Max. Pieces of Parallel 16
    S265 panel plot
    NO. Name
    1 Status indicator
    2 Battery negative
    3 Battery positive
    4 DIP switch
    5 CAN communication port
    6 RS485 communication port 1
    7 RS485 communication port 2
    8 Reset button
    9 Battery ground
    10 Power on/off switch

    S52565 lithium battery
