S5265 51.2V 65AH Solar Energy Low Voltage Battery Ampleness
MODEL:
65AH
Product Description
S5265 offers reliable and long-lasting performance, ensuring a consistent power supply for your solar system.
Leading Features
-
01
long service life
-
02
LFP Prismatic Cell
-
03
51.2V low-voltage
-
04
BMS
Certificates
Package
Careful packaging:
We focus on packaging quality, using tough cartons and foam to protect products in transit, with clear usage instructions.
Secure shipping:
We partner with trusted logistics providers, ensuring products are well-protected.
| Battery Type | LifePo4 |
| Mount Type | Rack Mounted |
| Nominal Voltage (V) | 51.2 |
| Capacity(Ah) | 65 |
| Nominal Energy (KWh) | 3.33 |
| Operating Voltage(V) | 43.2~57.6 |
| Max Charge Current(A) | 70 |
| charging Current(A) | 60 |
| Max Discharge Current(A) | 70 |
| discharging current(A) | 60 |
| charging Temperature | 0℃~+55℃ |
| Discharging Temperature | ﹣ 10℃-55℃ |
| Relative Humidity | 0-95% |
| Dimension(L*W*H mm) | 502*461.5* 176 |
| Weight(KG) | 46.5±1 |
| Communication | CAN, RS485 |
| Enclosure Protection Rating | IP53 |
| Cooling Type | Natural Cooling |
| Cycles Life | >3000 |
| Recommend DOD | 90% |
| Design Life | 10+ Years (25℃@77。F) |
| Safety Standard | CE/UN38.3 |
| Max. Pieces of Parallel | 16 |
| NO. | Name |
| 1 | Status indicator |
| 2 | Battery negative |
| 3 | Battery positive |
| 4 | DIP switch |
| 5 | CAN communication port |
| 6 | RS485 communication port 1 |
| 7 | RS485 communication port 2 |
| 8 | Reset button |
| 9 | Battery ground |
| 10 | Power on/off switch |
