N3H-5kw 8kw 10kw 12kw 16kw Solar Power PV Split Phase 110V 120V Hybrid Inverter
120/240V Split Phase Hybrid Inverter
The inverter converts photovoltaic DC power into AC powerto supply power to various load electricalequipment;
Or support selling to the grid;
Or store the DC power in the battery and supply it to the loadwhen electricity prices are high or when there is no grid power.
Inverters and batteries are used in homes and various commercial projects,
If you need wholesale inverters and batteries,
Or install in your local market,
Please contact us now!
| Technical Data | N3H-X10-US |
| PV Input Data | |
| MAX.DC Input Power | 15KW |
| NO.MPPT Tracker | 4 |
| MPPT Range | 120 – 500V |
| MAX.DC Input Voltage | 500V |
| MAX.Input Current | 14Ax4 |
| Battery Input Data | |
| Nominal voltage (Vdc) | 48V |
| MAX.Charging/Discharging Current | 190A/210A |
| Battery Voltage Range | 40-60V |
| Battery Type | Lithium and Lead Acid Battery |
| Charging Strategy for Li-Ion Battery | Self-adaption to BMS |
| AC Output Data(On-Grid) | |
| Nominal output power Output to Grid | 10KVA |
| MAX. Apparent Power Output to Grid | 11KVA |
| Output Voltage Range | 110- 120/220-240V split phase, 208V(2/3 phase), 230V(1 phase) |
| Output Frequency | 50/60Hz (45 to 54.9Hz / 55 to 65Hz) |
| Nominal AC Current Output to Grid | 41.7A |
| Max.AC Current Output to Grid | 45.8A |
| Output Power Factor | 0.8leading …0.8lagging |
| OutPut THDI | < 2% |
| AC Output Data(Back-Up) | |
| Nominal. Apparent Power Output | 10KVA |
| MAX. Apparent Power Output | 11KVA |
| Nominal Output Voltage L-N/L1-L2 | 120/240V |
| Nominal Output Frequency | 60Hz |
| Output THDU | < 2% |
| Efficiency | |
| Europe Efficiency | >=97.8% |
| MAX. Battery to Load Efficiency | >=97.2% |
| Object | Description |
| 01 | BAT inpu/BAT output |
| 02 | WIFI |
| 03 | Communication Pot |
| 04 | CTL 2 |
| 05 | CTL 1 |
| 06 | Load 1 |
| 07 | Ground |
| 08 | PV input |
| 09 | PV output |
| 10 | Generator |
| 11 | Grid |
| 12 | Load 2 |
