Wholesale hybrid solar inverter yekutanga fekitori yekugovera
120 / 240V inopenuka phatu hybrid inverter
| Technical data | N3H-X10-US |
| PV yekuisa data | |
| Max.dc yekuisa simba | 15KW |
| No.mppt tracker | 4 |
| MPPT Range | 120 - 500V |
| Max.dc Input Voltage | 500V |
| Max.inkut there | 14Ana4 |
| Battery Input data | |
| Nominal voltage (vdc) | 48V |
| Max.charging / kurasa zvazvino | 190A / 210a |
| Battery voltage range | 40-60V |
| Mhando bhatiri | Lithium uye tungamira acid bhatiri |
| Kuchaja zano kune li-ion bhatiri | Kuzvishingisa kune bMs |
| AC Output data (pa-grid) | |
| Nominal inoburitsa simba rinobuda kuGrid | 10kva |
| Max. One one Simba Rinobuda kuGrid | 11Kva |
| Output voltage range | 110- 120 / 220-240V akapatsanuka, 208V (2/3 chikamu), 230v (1 chikamu) |
| Kubuda frequency | 50 / 60HZ (45 kusvika ku58.9Hz / 55 kusvika 65Hz) |
| Nominal AC ikozvino kubuda kweGrid | 41.7a |
| Max.ac zvazvino kuburitsa grid | 45.8a |
| Chekunze Simba Factor | 0.8Leading ... 0.8lagging |
| Kubuda kweThi | <2% |
| AC yekubuda data (kumashure-kumusoro) | |
| Nominal. RINOGONESESA RUDZIDZO | 10kva |
| Max. RINOGONESESA RUDZIDZO | 11Kva |
| Nominal Output Voltage Ln / L1-L2 | 120 / 240V |
| Nminal Output Frequency | 60HZ |
| Kubuda thdu | <2% |
| Kushanda zvakanaka | |
| Europe kushanda | > = 97.8% |
| Max. Bhatiri Kuti Utore Kubudirira | > = 97.2% |
| Chinhu | Tsanangudzo |
| 01 | Bat Inpu / Bat Kubuda |
| 02 | Wifi |
| 03 | Poto yekutaurirana |
| 04 | CTL 2 |
| 05 | CTL 1 |
| 06 | Mutoro 1 |
| 07 | Pasi |
| 08 | PV yekuisa |
| 09 | PV inobuda |
| 10 | Jenareta |
| 11 | Grid |
| 12 | Mutoro 2 |
